Operating Temp

-60°C to +85°C (-76°F to +185°F)

Storage Temp

-76°F to +185°F (-60°C to +85°C)

Humidity

0-100 % RH (Non-condensing)

Operating Voltage

24 Vdc Nominal – (Range 18 to 32 Vdc)

Power Consumption

3W minimum (without heater), 15 W at 32 Vdc with heater on maximum.

Speed of Response

< 5 seconds (Typical)

Dimensions

100 mm Dia x 200 mm (4” Dia x 8” L)

Material

Copper free aluminium or 316 stainless steel

Entry Size

3/4 inch NPT or M25

Weight

Alu 5.5 lbs (2.5 Kg) / SS 13.2 lbs (6.0kg)

Outputs

Relay contacts (DPDT 2A at 30Vdc) – alarm and fault.
0-20mA plus fault alerts, HART®

Certifications

Class 1 Div 1 Groups B, C, D T4 Ambient –50°C to +85°C

Class 1 Zone 1 AEx/Ex db IIC T4 Ambient –50°C to +85°C

ATEX II 2 G Ex db IIC T4

IECEx Ex db IIC T4 Ambient –60°C to +85°C

INMETRO Ex db IIC T4

PESO Ex db IIC T4 Ta= -60°C to +85°C

CCC (China Fire Approvals) – Pending

GB-Ex of China – Pending

Performance Approvals

FM 3260

EN 54-10

Ingress – IP66 /NEMA 4X

SIL2 – IEC 61508
