PRODUCT CODE
XGB-A1-01-A-HA-R-CP
£1,528.80 £1,274.00

Crowcon Xgard Bright with MPS Sensor (0-100% LEL). Specifically designed for hydrogen with no need to calibrate over its 5+ year life.

Crowcon Xgard Bright / Alu / M20 - MPS Sensor (0-100% LEL)

Crowcon Xgard Bright / Alu / M20 - MPS Sensor (0-100% LEL)

The Crowcon Xgard Bright with the new state of the art Molecular Property Spectrometer (MPS) Sensor.

This MPS sensor can detect up to 15 different flammable gases such as Hydrogen, Methane, and Butane from just one sensor. Regardless of the operating environment, it is also fail-safe and does not require calibration.

What really makes this a breakthrough sensor is that Infrared sensors cannot detect Hydrogen meaning the only option until now was Pellistor sensors. But, with limitations around the accuracy and reliability of pellistors due to poisoning, the MPS sensor offers something that others just do not.

This Xgard Bright comes with 4-20mA and RS-485 modbus signals as standard. As well as alarm, relay and HART communications.

For more information about the Xgard Bright with MPS Sensor, speak to our sales team in the live chat, or call us on 0141 771 7749

Key Features
  • Prevents sensor poisoning
  • Reduction in false alarms
  • Multi-gas protection
  • IP65 Rating (IP66 with weatherproof cap)
  • Local display
Specifications

Size

156 x 166 x 109mm (6.1 x 6.5 x 4.3inch)

Cable Entry

2x M20 (stopping plug fitted to left-side entry)

Power

10-30Vdc. 3W max

Electrical Output

4-20mA current sink or source
RS-485 Modbus RTU
HART (Optional)

Weight

Aluminium alloy 1kg (2.2lbs)

Enclosure Material

ADC 12 aluminium alloy

Relay

Alarm 1, Alarm 2, Fault

SPST contacts rated 1A 30Vdc

Sounder Out

24Vdc (nominally), 250mA maximum load

Operating Temperature

-40°C to +70°C (-40°F to 158°F)

Note: sensor operating temperatures vary widely.

Refer to the sensor module datasheet or contact

Crowcon for specific sensor data.

Humidity

0 to 95% RH, non-condensing

Repeatability

+/- 2% FSD

Zero drift

+/- 2% FSD per year maximum

Ingress protection

IP65 (IP66 with weatherproof cap)

Approvals

ATEX and IECExEx II 2 G Ex db IIC T6 Gb

Ex tb IIIC T80ᶜ Db

II 2 G Ex db IIC T6 Gb

II 2 D Ex tb IIIC T80ᶜ Db

Certificate numbers:

TUV 16 ATEX 7908 X

IECEx TUR16.0035 X

EMC Compliance

EN50270: 2015

Standards

EN60079-0 :2012 + A11:2013
EN60079-1 :2014
IEC60079-0 :2011 Edition 6
IEC60079-1 :2014 Edition 7

Zones

Certified for use in Zone 1 and Zone 2 areas
