Drager Detection Tubes - Carbon Monoxide 2/a (Pack of 10)
Drager’s short-term gas detection tubes are a reliable way of accessing measurements of many different gases. These particular tubes are for carbon monoxide (2/a) and have a measurement range of 2 to 300 ppm.
They have a shelf life of 2 years, come in a pack of 10 tubes and are also able to detect carbonyl sulphide.
The Accuro Gas Detection Pump from Draeger Safety is required to use short-term gas detection tubes. View more information on this product by clicking here.
- Reach difficult measurement areas with the tubes, pump and accessories
- Carry out measurements on the spot
- Measurement results may take between 10 seconds and 15 minutes depending on the type of tube uses
- Applications for use include variations in concentrations in the workplace, contamination of breathing zones, pre-entry checks and confined space entry
Application Range | |
Standard Measuring Range: | 2 to 60 ppm / 25 to 300 ppm |
Number of Strokes n: | 10 / 2 |
Time for Measurement: | approx. 4 min / 50 sec. |
Standard Deviation: | ± 10 to 15 % |
Color Change: | white --> brownish |
Ambient Operating Conditions | |
Temperature: | 0 to 50 °C |
Absolute Humidity: | 2 to 20 mg H2O / L |
Reaction Principle | |
5 CO + I2O5 --> I2 + 5 CO2 | |
Cross Sensitivity | |
The following have no influence on the display of 10 ppm CO (respectively): 100 ppm hydrogen sulphide 50 ppm sulphur dioxide 15 ppm nitrogen dioxide 10 ppm CO + 200 ppm octane: display approx. 30 ppm 10 ppm CO + 40 ppm butadiene: display approx. 15 ppm 10 ppm CO +30 (100) ppm benzene: display approx. 15 (20 - 30) ppm 10 ppm CO + 40 ppm chloroform: display approx. 60 ppm 10 (60) ppm acetylene: display approx. 5 (15) ppm With the insertion of a carbon attachment tube (CH 24101), 10ppm CO can still be measured in the presence of 10000 ppm n-octane |
