Drager Oxygen (1-30Vol%) - Chip

Drager Safety's chip range is now obsolete. For alternative products, please see the Drager Accuro Pump and Tubes.

Please note this product is currently discontinued.

Subscribe to back in stock notification

I have read & accept the Privacy Policy

Product description

Oxygen (1-30 Vol%) short-term measurement chip from Drager. This pack contains 1 piece.

NOTE: This product has a shelf life of 2 years.

Specification

APPLICATION RANGE

Measuring Range	1 to 30 Vol% (20 °C, 50% r.h.)
Measuring Time	approx. 100 to 600 s
Rel. Standard deviation	± 18%

AMBIENT OPERATING CONDITIONS

Temperature	1 to 40 °C
Absolute Humidity	1 to 40 mg/L (corresp. 2 to 80% r.h. at 40 °C)
Air Pressure	700 to 1100hPa

CROSS SENSITIVITY
No influence at 1 Vol% O2 by	< 60 ppm CO
	< 0.5 Vol% CO2
	< 200 ppm xylene
	< 100 ppm tri- and perchloroethylene
	< 1000 ppm acetone
	< 850 ppm ethyl acetate
