Drager - Pac 7000 Carbon Monoxide (CO) Personal Gas Detector

PRODUCT CODE:: 8318673

Please note: this product is now obsolete. See the Drager Pac 6500 as an alternative product.

Please note this product is currently discontinued.

Subscribe to back in stock notification

I have read & accept the Privacy Policy

Product description

Drager - Pac 7000 Carbon Monoxide (CO) Personal Gas Detector

Please note: this product is now obsolete. See the Drager Pac 6500 as an alternative product.

The Drager Pac 7000 is a small, portable gas detector used in industrial settings and can monitor harmful concentrations of carbon monoxide.

The Pac 7000 is highly reliable and provides fast and accurate results of the presence of carbon monoxide gas (CO).

This personal gas monitor from Draeger is designed for long-term operation and can make bump testing easier by automating the process (when used in conjunction with the Drager Bump Test Station ).

Bump tests can be configured to match specific safety regulations and the Pac 7000 also has an automatic shut-off function if, after a set period of time, function tests have not been carried out.

Key Features

Impact-resistant, protective rubber coating – impervious to corrosive chemicals
Optimised protection against electromagnetics
Adjustable crocodile clips allows monitor to be fastened to clothing
Easy to replace battery and sensor on-site without any additional equipment
Replaceable water and dust filter
Immediate display of gas hazards
Adjustable data logger records all concentrations and events with respective dates and times (120 hours @ 1 data set per minute)
Data can be downloaded via Drager Pac Vision, Drager CC-Vision software or Drager GasVision software
Integrated menu for calibration options
Password protection option for fresh air or span calibration
Gas Inlets at the top and front of device
Automated bump test process with Drager Bump Test Station

Specification

Range (ppm)	0 to 1999 ppm
Resolution (ppm)	1 ppm
Dimensions (W x H x D)	84 x 64 x 25 mm; 3.3 x 2.5 x 1.0 in.
Weight	120 g; 3.8 oz.
Ambient Conditions	Temperature: -30 – 50 °C; -20 – 120 °F Pressure: 700 – 1300 hPa Humidity: 10 – 90 % r. h.
Battery Life	5500 hours; unlimited lifetime (Typical at 25° C)
IP Rating	IP 65 – projection of water
Alarms	Two-tone-alarm typical > 90 dB at a distance of 30 cm Two alarm lights located at corners of monitor for 360° visibility Adjustable TWA and STEL alarms Low battery and error warning
Default Alarm Threshold	30/60 ppm (A1/A2)
Approvals	CE-Sign (89/336/EEC, 94/9/EC) ATEX II 1 G EEx ia IIC, T4; I M 1 EEx ia I, T 4 UL Class I, II, Div 1, Group A, B, C, D, E, F, G, Temp. Code T4 cUL Class I, II, Div 1, Group A, B, C, D, E, F, G, Temp. Code T4 IECEx EEx ia IIC, T4 Marine Equipment Directive 96/98/EC Measurement Performance Certificate (acc. to ATEX) EN 45544 (CO, H2S), EN 50104 (02), EN 50271
What’s Included	Pac 7000 Detector with Drager XXS Sensor as specified Operation and maintenance manual Crocodile clip (installed) High capacity Lithium battery installed
