- Description / Features / Spec
Honeywell BW Icon and Icon+
The latest additions to Honeywell BW's gas detection family is the BW Icon and the BW Icon+. This is a rugged diffusion gas monitor, capable of detecting up to four gases. There are two configurations available: IR LEL / O2 / H2S / CO or IR LEL / O2 / H2S / SO2 and both are available on the Icon and Icon+.
What's the Difference Between the Icon and Icon+?
The BW Icon has a fixed two-year life. Once the unit is switched on and activated the Icon's lifetime begins and there's no need to replace the battery. The Icon+ is a serviceable version and can be calibrated every 6 months.
The BW Icon and Icon+ are unique to other detectors in the BW family as its user interface is icon-driven. Instead of the standard screen, the front of the unit will show eright icons including alarm status, STEL and TWA readings, battery status, bluetooth and bump/calibration status. This will allow quick and easy indication and understanding of what the detector requires or is picking up. Both have a triple alarm system with visual, vibrating, audible (95 dB) for low, high, TWA, STEL, negative drift, over limit, and multi-alarm.
The BW Icon may have a two-year lifetime but it's simple operation and intuitive features make it a great addition to any gas detection fleet. The Icon+ offers a long-term cost of ownership. Both units have been designed to run for approximately two months on a single charge before needing to be recharged. This provides a great advantage when looking to reduce downtime. It can be charged via a USB, so can be powered up on the go.
Honeywell's Intelliflash system can be found on the BW Icon and Icon+ to give the user a quick indication of the unit's status and alert them to any maintenance actions like bump testing. It also has IR connectivity for use with the IntelliDoX and the IR connectivity kit. Both Icon monitors will come with BLE bluetooth enabled as standard to allow connection with their Safety Suite, third party devices and TouchConnect. This software can be used to configure user options such as changing high/low/TWA/STEL alarm set points, latching alarms, assign worker and location assignments and always on.
- Intelliflash green light will show compliance and amber light will show need for maintenance
- Simple one-button operation
- Data-logging and event-logging capability
- Can be bump tested and calibrated
- IP 66 and 68 rated
- Icon-driven user interface
- Klick fast system - uses various accessories to wear the device in a number of ways - must be purchased separately
- Uses 1 Series sensors
- External filters can be accomodated for quick maintenance
- Performs a self-test upon activation and will automatically performs analog sensor diagnostic every 10 minutes and digital sensor diagnostics every second
Dimensions and Weight
- 108.2 x 61.5 x 43.2 mm (4.29 x 2.44 x1.7 in) and 185g (6.5oz) with Alligator Clip
- NDIR-CH4 - 0-100% LEL (Resolution 1% LEL)
- O2 - 0 to 30% Vol (Resolution 0.1% Vol)
- CO - 0-2000ppm (Resolution 1ppm)
- H2S - 0-200ppm (Resolution 1ppm (can be set to 0.1ppm)
- SO2 - 0-150ppm (Resolution 0.1ppm)
- NDIR-CH4 -40°C to 60°C (-40°F to 140°F)
- O2 -40°C to 60°C (-40°F to 140°F)
- CO -40°C to 60°C (-40°F to 140°F)
- H2S -40°C to 60°C (-40°F to 140°F)
- SO2 - 20°C to 50°C (-4°F to 122°F) intermittent
- 40°C to 55°C (-40°F to 131°F)
5% to 95%
Typical Battery Life
Two months (with NDIR CH4 sensor) on a 4.5 hour charge and up to 4 months if the detector is turned off at end of each shift
Certifications and Approvals
ATEX, IEC Ex, contains FCCID, contains IC
Three-year warranty for sensors and detector
*The infrared LEL sensor used in Honeywell BW Icon cannot detect hydrogen and acetylene. For applications involving these combustible gases, consider a catalytic-bead LEL sensor as found in the Honeywell BW MicroClip Series.
