PRODUCT CODE
G02-AE10-100
£573.60 £478.00
ToxiRAE Pro (PGM-1860) Oxygen (O2) Gas Detector Non-Wireless


ToxiRAE Pro (PGM-1860) Oxygen (O2) Gas Detector Non-Wireless

ToxiRAE Pro (PGM-1860) Oxygen (O2) Gas Detector Datalogging / Non-Wireless

The ToxiRAE Pro is ideal for applications and industries such as agriculture, chemicals, fire service/hazmat use, oil and gas, pharmaceutical, pulp and paper, steel manufacturing and water and wastewater.

It’s a single gas detector from RAE Systems which monitors oxygen depletion levels.  It’s easy to use, is intrinsically safe and has a rugged housing which ensures the detection of O2 gas is carried out safely.

This non-wireless instrument is available with over 20 interchangeable sensors, each to suit a variety of gases.  The sensors are intelligent with the ability to store calibration data.

It’s important to note that non-wireless models cannot be upgraded to wireless.

Key Features
  • LED backlighting is activated on the large LCD screen
  • Readings such as gas concentrations in ppm, battery status, data logging on/off, wireless on/off and reception quality – STEL, TWA and peak values are displayed
  • Continuous datalogging capacity (three-months at 1 minute intervals)
  • User-configurable datalogging intervals (from 1 to 3600 seconds)
  • Sensors, filter and Li-ion battery are replaceable
  • 2-button operation
  • Fully automatic bump testing and calibration with the AutoRAE 2 – available from Frontline Safety
Specifications
Range 0 to 30% Vol.

Resolution

0.1 % Vol.
Size

4.6” x 2.4” x 1.2” (118 x 60 x 30 mm)

Weight 7.76 oz (220g)

Operating Period

>30 hours (normal operation, non-wireless) Recharge time <4 hours through charging cradle (rechargeable Li-ion battery)
Sampling Diffusion
Humidity 0-95% RH non-condensing
Temperature -4° to 131°F (-20° to 55°C)
IP Rating IP-65 for dust & water ingress protection
Alarms
  • Audible 95dB @ 30cm
  • Vibration
  • Visible Alarm (flashing bright LEDs)
  • On-screen indication of alarm conditions
Hazardous Location Approvals
  • CSA – Class I, Division 1, Groups A, B, C and D, T-code T4, Class I, Zone 0 A/Exia IIC T4
  • ATEX – CE II 1G, Ex ia IIC Ga T4
  • IECEx – Ex ia IIC Ga T4
  • China Ex: Ex ia IIC T4
CE Compliance (European Conformity) EMC directive 2004/108/EC, R&TTE directive: 1999/5/EC, ATEX directive 94/9/EC
Warranty 2 years on non-consumable components; 1 year on sensor, battery and other consumable parts
What’s Included
  • ToxiRAE Pro Monitor with sensor as specified, alligator clip, protective rubber boot, rechargeable battery installed
  • Charging and PC communication cradle
  • PC Communication Cable
  • AC adapter (100 to 240 V, 50/60 Hz AC to 12 V DC)
  • Calibration adapters
  • Quick Start Guide
  • CD with documentation
  • ProRAE Studio II software for PC-based instrument configuration and data management
  • Calibration card, quality certificate and warranty/registration card
